Need help?Do you have a question about the Datalogic QuickScan QD2430 and is the answer not in the manual?
General| Scanner Type | 2D Area Imager |
|---|---|
| IP Rating | IP42 |
| Print Contrast Ratio (Minimum) | 25% |
| Motion Tolerance | 25 IPS |
| Ambient Light | 0 - 100, 000 lux |
| ESD Protection (Air Discharge) | 16 kV |
| Operating Temperature | 0 to 50 °C / 32 to 122 °F |
| Storage Temperature | -40 to 70 °C / -40 to 158 °F |
| Humidity (Non-Condensing) | 5 - 95% |
| Light Source | Red LED |
| Resolution | 0.1 mm (4 mil) |
| Interface | USB, RS-232, Keyboard Wedge |
| Drop Resistance | Withstands drops from 1.5 m / 5.0 ft |
| Weight | 145.0 g / 5.1 oz |
| Image Sensor | 752 x 480 pixels |
| Decode Capability | 1D / Linear Codes, Stacked Codes, 2D Codes, Postal Codes |
| Reading Angle | Pitch: +/- 65°, Roll: 360°, Skew: +/- 60° |
| Power Supply | 5 VDC +/- 5% |
