Datalogic QuickScan QD2430 User Manual

Technical Specifications
20 QuickScan™ QD2430
Technical Specifications
The following table contains Physical and Performance Char-
acteristics, User Environment and Regulatory information.
Item Description
Physical Characteristics
Color Black & white
Dimensions
Height 6.4"/163 mm
Length 3.6"/91 mm
Width 1.6"/41 mm
Weight (without cable) Approximately 5.1 ounces/145 g
Electrical Characteristics
Voltage & Current
Input Voltage: 4.5 - 14.0VDC
Operating (typical): 140mA
Operating (max): 380mA
Idle/standby (typical): 50mA
Performance Characteristics
Light Source LEDs
Roll (Tilt) Tolerance Up to ± 360°
Pitch Tolerance ± 65°
Skew (Yaw) Tolerance ± 60°
Print Contrast Minimum 25% minimum reflectance
