Datalogic QuickScan QD2430 User Manual

Technical Specifications
Quick Reference Guide 21
Depth of Field (Typical)
a
a. 13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade A, typical environmental light,
20°C, label inclination 10°
Symbology
Code 39
5mil: 0.2" - 5.9" (0.5 - 15cm)
10mil: 0" - 8.7" (0 - 22cm)
20mil: up to 16" (40cm)
EAN
7.5mil: 0" - 5.9" (0 - 15cm)
13mil: 0.2" - 13.8" (0.5 - 35cm)
PDF-417
6.6mil: 0.39" - 5.1" (1.0 - 130cm)
10mil: 0" - 8.3" (0 - 21cm)
15mil: 0.2" - 9.5" (0.5 - 24cm)
DataMatrix
10mil: 0.39" - 5.1" (1.0 - 13 cm)
15mil: 0" - 7.1" (0 - 18cm)
QR Code
10mil: 0.2" - 5.1" (0.5 - 13cm)
15mil: 0" - 7.1" (0 - 18cm)
Minimum
Element Width
Standard Range:
1D Min Resolution = 4 mil
PDF-417 Min Resolution = 5 mil
Datamatrix Min Resolution = 7.5 mil

Datalogic QuickScan QD2430 Specifications

General

Scanner Type	2D Area Imager
IP Rating	IP42
Print Contrast Ratio (Minimum)	25%
Motion Tolerance	25 IPS
Ambient Light	0 - 100, 000 lux
ESD Protection (Air Discharge)	16 kV
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-40 to 70 °C / -40 to 158 °F
Humidity (Non-Condensing)	5 - 95%
Light Source	Red LED
Resolution	0.1 mm (4 mil)
Interface	USB, RS-232, Keyboard Wedge
Drop Resistance	Withstands drops from 1.5 m / 5.0 ft
Weight	145.0 g / 5.1 oz
Image Sensor	752 x 480 pixels
Decode Capability	1D / Linear Codes, Stacked Codes, 2D Codes, Postal Codes
Reading Angle	Pitch: +/- 65°, Roll: 360°, Skew: +/- 60°
Power Supply	5 VDC +/- 5%
