Datalogic ADC, Inc.
959 Terry Street
Eugene, OR 97402
USA
Telephone: (541) 683-5700
Fax: (541) 345-7140
©2013-2014 Datalogic ADC, Inc.
An Unpublished Work - All rights reserved. No part of the con-
tents of this documentation or the procedures described
therein may be reproduced or transmitted in any form or by
any means without prior written permission of Datalogic ADC,
Inc. or its subsidiaries or affiliates ("Datalogic" or “Datalogic
ADC”). Owners of Datalogic products are hereby granted a
non-exclusive, revocable license to reproduce and transmit
this documentation for the purchaser's own internal business
purposes. Purchaser shall not remove or alter any proprietary
notices, including copyright notices, contained in this docu-
mentation and shall ensure that all notices appear on any
reproductions of the documentation.
Should future revisions of this manual be published, you can
acquire printed versions by contacting your Datalogic repre-
sentative. Electronic versions may either be downloadable
from the Datalogic website (www.datalogic.com) or provided
on appropriate media. If you visit our website and would like
to make comments or suggestions about this or other Data-
logic publications, please let us know via the "Contact Data-
logic" page.
Disclaimer
Datalogic has taken reasonable measures to provide informa-
tion in this manual that is complete and accurate, however,
Datalogic reserves the right to change any specification at any
time without prior notice.
Datalogic and the Datalogic logo are registered trademarks of
Datalogic S.p.A. in many countries, including the U.S.A. and
the E.U. All other brand and product names may be trade-
marks of their respective owners.
Patents
See www.patents.datalogic.com
for patent list.
This product is covered by one or more of the following pat-
ents:
Design patents: EP002158717, ZL201330271434.1
Utility patents: EP0996284B1, EP0997760B1, EP0999514B1,
EP1128315B1, EP1396811B1, EP1413971B1, EP1828957B1,
JP4435343B2, US6478224, US6512218, US6513714,
US6561427, US6808114, US6997385, US7053954, US7075663,
US7234641, US7387246, US7721966, US8245926, US8561906

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Datalogic QuickScan QD2430 and is the answer not in the manual?

Datalogic QuickScan QD2430 Specifications

General IconGeneral
Scanner Type2D Area Imager
IP RatingIP42
Print Contrast Ratio (Minimum)25%
Motion Tolerance25 IPS
Ambient Light0 - 100, 000 lux
ESD Protection (Air Discharge)16 kV
Operating Temperature0 to 50 °C / 32 to 122 °F
Storage Temperature-40 to 70 °C / -40 to 158 °F
Humidity (Non-Condensing)5 - 95%
Light SourceRed LED
Resolution0.1 mm (4 mil)
InterfaceUSB, RS-232, Keyboard Wedge
Drop ResistanceWithstands drops from 1.5 m / 5.0 ft
Weight145.0 g / 5.1 oz
Image Sensor752 x 480 pixels
Decode Capability1D / Linear Codes, Stacked Codes, 2D Codes, Postal Codes
Reading AnglePitch: +/- 65°, Roll: 360°, Skew: +/- 60°
Power Supply5 VDC +/- 5%
