M-Class 53
System Settings (continued)
DPL EMULATION
(not available with M-4306)
Determines SOP Emulation (start of print (<STX>O)) see above, Column
Emulation (see above), positions barcodes as does selected printer.
STANDARD
Start of print 220; the below exceptions are disabled.
ALLEGRO
PRODIGY PLUS
PRODIGY
Allegro, Prodigy Plus, and Prodigy emulations enabled:
Data Terminator – I 2 of 5 Barcodes (IDs D, J, and L), the first non-numeric
character processed will terminate the barcode data field.
Bar Size – I 2 of 5 Barcode (ID L), when the bar size is specified greater than P
(25), the size is automatically decreased to 10.
Human Readable Fonts – The EAN and UPC barcodes (IDs B, C, F, G, M, and
N) print a fixed font size.
Lines and boxes: Rotations 2 and 4 are affected by the vertical multi-plication
factor defined in the DPL Dxx command.
Column positions greater than the printhead width are adjusted back to the
printable area and printed.
Barcodes (rotation 3, upside down / right to left) with row position less than
barcode height result in row position equal to barcode height, that is, barcodes
falling off label leading edge are pushed back onto the label.
<STX>L (Label Command) followed by no printable fields result in no paper
movement. (When disabled a blank label is printed).
Allegro Only:
The row position is calculated based on 194 DPI.
COLUMN EMULATION
* Not available in M-4306
Compensation for location of column position 0 via columnar dots per inch (dpi)
emulation.
203 in (180 - 250)
Dpi emulation, smaller numbers shrink text from right to left.
