Datamax Mark II M-4206 User Manual

M-Class 59
Communications (continued)
SPEED COMMANDS
Allows the user to disable the DPL speed commands (Print, Feed, Slew, and
Reverse).
ENABLED
Normal printer operating mode.
DISABLED
DPL speed commands are ignored. The speeds are controlled via the menu setting;
see Section 5.1.3.
TOF SENSING COMMANDS
Allows the user to disable the DPL Top of Form commands (Gap, Continuous, and
Reflective).
ENABLED
Normal printer operating mode.
DISABLED
DPL TOF commands are ignored. The TOF is controlled via the menu setting; see
Section 5.1.2.
SYMBOL SET COMMAND
Allows the user to disable the DPL Single and Double Symbol Set selection
commands.
ENABLED
Normal printer operating mode.
DISABLED
DPL Symbol Set commands are ignored. The Symbol Set selection is controlled
via the menu setting; see Section 5.1.5.
CNTRL-CODES (DATA)
Allows the user to remove control codes (data < 20 Hex) from the data fields. The
selected line terminator is processed.
ENABLED
Normal printer operating mode.
DISABLED
DPL Control Code (SOH, STX, CR, ESC, and ^) functions are ignored.
STX-V SW SETTINGS
Allows the user to disable DPL software switch settings commands.
ENABLED
Normal printer operating mode.
DISABLED
DPL option-enable command (<STX>V) is ignored.

Datamax Mark II M-4206 Specifications

General

Print Resolution	203 dpi
Type	Label Printer
Print Method	Thermal Transfer
Max Print Speed	6 inches per second
Memory	16 MB SDRAM, 8 MB Flash
Interfaces	USB, Serial, Parallel
Media Width	4.5 inches
Media Length	0.25" to 99"
Max Print Width	4.25 inches (108 mm)
