Datamax Mark II M-4206 User Manual

74 M-Class
Advanced Entry Calibration (continued)
Step Operator Action Displayed Message Comment
11
Proceed according to your
media type:
Die-cut stock: strip the media
from the backing and then
reinsert it into the sensor; adjust
the Sensor Eye Mark over the
center of the backing.
Notched stock: adjust the
Sensor Eye Mark over the
center of the notch.
Reflective stock: Adjust the
Sensor Eye Mark over the
center of the facedown black
mark.
Press the
Key to select
the setting and then record the
sensor reading in a table similar
to the one shown after Step 12,
as a TOF Value.
Next, press the
FWD
Key to
increment the Gain Number.
Repeat for each of the Gain
Numbers (00-32).
!
HBJO!USBO!!!!!=zzz?!
+11!!!!!!!!)1!.!42*!
!
Or, for reflective media:
HBJO!SFGM!!!!!=zzz?!
+11!!!!!!!!)1!.!42*!
Where ‘yyy’ is a numerical value representing the
current sensor reading: useful in locating the best
sensor position.
 Note: Never position the sensor over a perforation
when recording a sensor reading.
 Note: Do NOT move the position of the Media Sensor after it has been adjusted.

Datamax Mark II M-4206 Specifications

General

Print Resolution	203 dpi
Type	Label Printer
Print Method	Thermal Transfer
Max Print Speed	6 inches per second
Memory	16 MB SDRAM, 8 MB Flash
Interfaces	USB, Serial, Parallel
Media Width	4.5 inches
Media Length	0.25" to 99"
Max Print Width	4.25 inches (108 mm)
