M-Class 77
Advanced Entry Calibration (continued)
Step Operator Action Displayed Message Comment
16
Press the
Key.
Using the
FWD
or the
REV
Key, set the ‘Paper’ level to the
value determined in the
previous step. Press the
Key to set the entry (indicated
by the ‘*’) and advance the
menu.
Repeat for the ‘Gap’ (or
‘Mark’) and ‘Empty’ levels.
!
QBQFS!TFOTPS!MFWFM!
Q+2:9!H+195!F+125!
!
!
HBQ!TFOTPS!MFWFM!
Q+2:9!H+195!F+125!
!
!
FNQUZ!TFOTPS!MFWFM!
Q+2:9!H+195!F+125!
!
!
!
!
Or, for reflective media:
!
QBQFS!TFOTPS!MFWFM!
Q+126!N+292!F+324!
!
!
NBSL!TFOTPS!MFWFM!
Q+126!N+292!F+324!
!
!
FNQUZ!TFOTPS!MFWFM!
Q+126!N+292!F+324!
The selection will flash and the display heading will
change to indicate the item for entry.
17
After all entries have been
made, press the
Key to
back out of the menu and then
press the
Key
to save
the settings and return to the
Ready Mode.
!
TBWF!DIBOHFT@!
FOUFS!LFZ!>!ZFT!
!
!
!
From ‘Ready’, press the FEED Key to advance to
the next label TOF.
Note: If the Advanced Entry Calibration fails, try the following procedure.
Re-enter Media Settings / Calibration / Advanced Entry / Sensor Gain and lower the selected Gain Setting number by one (to
make the sensor less sensitive). Select the new Gain Setting, save the changes, exit the menu, and then test your media.
Repeat the procedure until a usable media setting is obtained.
