13. Lock the position of the 150 x 150 PTZ Scissor
Lift, Item G with the 16mm long screw, Item
N.
14. Install the 15” LCD Control Unit, Item A by
inserting the the 9mm long ¼ thumb screw with
red dot, Item J through the slot in the TP-900
metal base tray with tripod plate, Item F.
