DT9502
36 20171205-V3
34. You see this
on the display. This is the value of
L1.HH. It can be changed to any values between 00.0 and
99.9. The digit at the left side is blinking.
35. Pressing the ► button you can select the next digit.
36. Pressing the
▲ button you can increase the value of the
blinking digit:
,,,,,,,,,, etc.
37. After you have set the value of the hysteresis, press the
MENU button to exit from this sub-menu item, and you see
this:
.
Exit from the menu item 1. After finishing the settings, press the MENU button to exit
from the given menu item, and you see this:
.
(2. If you want to change the setting you have done just
now, or if you just want to check what you have typed in, go
on with the operation from point 2 of the Sequence of
operations.)
(3. If you don’t want to exit the menu (you want to do further
settings), then you may select the desired menu items by
pressing the
▲ button.)
Exit from the menu
1. Press the MENU button. First the mnemonic
(Save), then the mnemonic
(Exit) are shown on the
display. With this the storing of the settings is completed.
The instrument has exited the menu and goes on with the
measurement.
You find a detailed training material on the limit outputs in
the Appendix, in Chapter 10.8 Limit outputs.
