DT9502
20171205-V3
29
7.3. Display modes of limit output status
(01. menu item)
Function The state of the limit outputs (whether they are switched on
or off) can be displayed. Here you can define the conditions,
on which displaying should depend.
[Default factory setting: OFF]
Sequence of operations 1. Enter the menu by the user or the supervisor code.
Chapter 7.1. Typing the code in describes how you can
type the code in. You see on the display: .
2. Enter the given menu item by pressing the ENTER
button.
3. You can read the mnemonic
on the display. The
mnemonic is blinking.
4. Pressing the ▲ button, select the desired display mode.
: switched off
The instrument never displays the state of limit outputs
[default factory setting]
•: Dynamic button (Dynamic Button)
It displays the state of limit outputs as long as the ENTER
button is kept pressed.
•: Timed button (Timed Button)
It displays the state of limit outputs for a period as long as
the ENTER button is kept pressed + for 2.5 seconds.
•: Static button (Static Button)
Displaying the state of limit outputs can be switched on/off
by pressing the ENTER button.
•: Automatic: when changed (Auto: Change)
After a change has taken place in the state of limit outputs
(switching off or on) it displays for a period of 2.5 seconds.
If you keep the ENTER button pressed down, the
measurement results are displayed.
•: Automatic: periodical (Auto: Periodical)
In every 2.5 seconds it displays the states of limit outputs
automatically for 2.5 seconds.
If you keep the ENTER button pressed down, the
measurement results are displayed.
