BLUEPAD-50 PLUS MSR USER GUIDE
UM 07.01.36/v1.3.0 1 DATECS Page 14 of 25
Setup
When a BluePad-50 Plus is switched on and the Power button is kept pressed, on the display will be
shown the name and the version of the Secure Boot Loader and the firmware.
Service personnel can access two different system modes: “System Mode” and “Application
Download Mode”.
SYSTEM MODE
To enter System mode on the BluePad-50 Plus, the button has to be maintained pressed while
switching on the PINPAD. A characteristic sound is played and on the display appears the “SYSTEM
MODE” menu.
The following keyboard buttons can be used in service mode:
: move through the list one position upwards
: move through the list one position downwards
: selection of the active option
: return to previous level or exit the service mode
The following menu options can be selected in service mode:
INFO VERSION
INFO HARDWARE
INFO KEYS
TEST DISPLAY
TEST KEYBOARD
TEST SCR
COMMUNICATION MODE
INFO VERSION
Shows the serial numbers and the versions of the detached program modules:
DEV SN - BluePad-50 Plus serial number
USIP SN - USIP serial number
USIP VER - USIP version
ISBL VER - USIP Boot loader version
HAL VER - USIP Hardware Abstraction Layer (HAL) version
LOAD VER - Secure Boot Loader (SBL) version and name
FW VER - Firmware version and name
PROM VER - Prompts version
APPL VER - Application version and name
PKFA VER - Version of the public key used for firmware authentication
PKAA VER - Version of the public key used for application authentication
PKKA VER - Version of the public key used for manufacturing keys authentication
