BLUEPAD-50 PLUS MSR USER GUIDE
UM 07.01.36/v1.3.0 1 DATECS Page 16 of 25
APPLICATION DOWNLOAD MODE (Firmware/Application update via USB interface)
To enter application download mode on the BluePad-50 Plus, the button has to be maintained
pressed while switching on the PINPAD. A characteristic sound is played and on the display appears
the name and version of the Secure Boot Loader.
When application download is initiated, on the display is shown the progress in percentages of the
downloading process.
To exit the mode, press or Power buttons.
The Application download process shall not be interrupted to prevent memory corruption. If the
buttons or Power are pressed during the downloading process, the application integrity checking
will fail on booting up and process will have to be repeated.
COMMUNICATION PARAMETERS
The default USB VC serial port communication parameters are the following:
115200bps
8bit
1 stop bit
no parity
SETTINGS IN APPLICATION(DEPENDS OF THE APPLICATION)
RS SPEED 115200*
USB MODE DISABLE*/DEVICE/HOST
BLUETOOTH Settings
Mode: ENABLE/DISABLE
ADDR: MAC ADDRESS of the Bluetooth
NAME: Bluetooth name
PASS: Bluetooth password
PAIR: DISCOVERABLE/HIDDEN
AUTO: ENABLE/DISABLE
VER: Bluetooth firmware version
MASTER RESET: return to default settings
FW UPDATE
AUTO OFF 60min*/120min/180min/240min/DISABLE/1min//5min/10min/
15min/30min/45min
