Avance
11-28 M1204616
Ventilator operating specifications
Pneumatics
Fresh gas
compensation
Pressure
Volume
Oxygen
Gas source Anesthesia system
Gas composition Medical Air or O2
Nominal supply pressure 350 kPa (50 psi)
Pressure range at inlet 240 to 700 kPa (35 to 102 psi)
Peak gas flow 120 l/min at 240 kPa (35 psi), 0.75
seconds
Continuous gas flow 80 l/min at 240 kPa (35 psi)
Flow valve range 1 to 120 l/min at 240 kPa (35 psi)
Flow compensation range 150 ml/min to 15 l/min
Gas composition O2, N2O, Air, anesthetic agents
Patient airway pressure range -20 to +120 cmH2O, +/- 1 cmH2O
resolution
High pressure alarm set range 12 to 100 cmH2O, 1 cm increment
Sustained pressure alarm range 6 to 30 cmH2O, 1 cm increment
Display range -20 to 120 cmH2O
Tidal volume display range 0 to 9999 ml, 1 ml resolution
Setting range 20 to 1500 ml
Minute volume 0.0 to 99.9 liters, 0.1 liter resolution
Breath rate 4 to 100 bpm (non-spontaneous)
2 to 60 bpm (spontaneous)
1 bpm resolution
Volume sensor type Variable flow orifice
Display range 0 to 110% O2
Display resolution 1% increments
Sensor type Galvanic fuel cell
Measurement range 0 to 100% O2
Measurement accuracy Better than ± 3% of full scale
Cell response time 35 seconds
Note: Response time of cell and
adapters is measured using the test
method described in ISO 7767 (1997).
Low O2 alarm range 18% to 99%
High O2 alarm setting 19% to 100% or Off
Note: Low O2 limit may not be set
above high O2 limit. High O2 limit may
not be set below the low O2 limit.
Expected cell life Four months of shelf life (23°C room
air) and one year of normal operation.
