Datex-Ohmeda Avance - Setting Loop Type; Setting Loop Graph Scaling

3 Operation
M1204616 3-25
Setting loop type 1. Push the Spirometry key.
2. Select Loop Type and set the loop type.
•Set to P-F for Paw-Flow.
•Set to F-V for Flow-Volume.
•Set to P-V for Paw-Volume.
Setting loop graph
scaling
Use the Scaling menu to set the scales of the spirometry loop graph.
The available settings for the volume, Paw, and flow graph axes are
dependent on the set patient type of adult or pediatric.
The AUTO selection automatically adjusts the volume, Paw, and flow
axes of the loop graph based on the minimum and maximum breath
reading shown in the waveform.
The Linked selection links the adjustment of the volume, Paw, and
flow axes of the loop graph together. Change one of the scales and
the remaining two scales automatically change based on the one set
scale.
The Indep selection allows the axes of the loop graph to be changed
separately for the volume, Paw, and flow axes.
1. Push the
Spirometry key.
Spirometry
Loop Type P-V
Scaling
Spiro Setup
Save Loop
Reference Loop None
Erase Loop None
Previous Menu
Scaling
Scaling AUTO
Vol Scale
Paw Scale
Flow Scale
Previous Menu
