Datex-Ohmeda Avance - Using the Bag Support Arm

Avance
2-6 M1204616
1. Bag support arm
2. Auxiliary Common Gas outlet (ACGO) switch
3. ACGO port
4. EZchange canister module (CO2 bypass)
5. EZchange canister release
6. Condenser drain button
7. Condenser
Figure 2-4 • Breathing system options
Using the bag
support arm
Use the optional bag support arm to hold the breathing circuit bag.
1. To raise the bag support arm, squeeze the button and rotate the
arm up to the top position.
2. To lower the bag support arm, squeeze the button and rotate the
arm down to the lower position.
1
2
3
4
5
6
7
AB.91.136
AB.82.023
