DashboardDisplays
watt
Theheartratedisplaystheheartrate.Whenonlytheupwardpointingarrowis
displayedinthemiddle,thenthismeansthattheheartrateistoolowtoensure
aneffectivetraining.Inversely,whenonlythedownwardpointingarrowis
displayedthentheheartrateistoohigh.Ifthearrowstartsblinkingthenthe
loadistoohighandtheusershouldmoderatethetraining.
Speedanddistancewindow:thiswindowshowstheactualspeedorthe
correspondingdistancecovered.Pressingthecontrolbuttonswitchesbackand
forthbetweenthesetwovalues.Seealsopage5.
TheRPMdisplayindicatesthevelocityinrevolutionsperminute.
(+=pedalfaster,-=pedalslower).
Thegraphicscreendisplaystheprograms.Theload(inwatt)isshownonthe
scaleontheleftsideofthescreen.Thetrainingtimeisshownontheloweraxis.
Inheartratecontrolledprogramsthesystemdisplays100beatsperminuteat
the200wattposition.
Inheightprofileprogramsthetimeaxisshowsthedistancecovered,whilethe
wattaxisshowstheheightprofile.
Note:theillustrationsmaybechangedwithoutnotice!
13
:
08
3
250
0.0
+
0
128
OK
Thewattwindowshowstheloadinwatt.Thedisplayedwattvaluewillblinkto
indicatereachingeitherthewattloadlimitofthedeviceorthewattloadlimitof
theuser.Italsoshowstherelaxvaluewithrelaxationexercises.
Youcanindividuallysetupwhichdatayouwhishtoview:clock,trainingtime,
speed,distanceordissipatedenergy(inkJoule).Youcanswitchbackandforth
withaseconddisplaybypressingthecontrolbutton.Seepage5.
Theuserwindowspecifiestheusernumber(1to4orguest0).
