1. Remove the top plate of the Model 10CJB-2 and locate
the three programming jumper pads corresponding to the
10CJB-2 channel you have connected to the 4077 ("A" or
"B"). The pads are near the left edge of the 10CJB-2
circuit board.
2. Place a solder drop between the center pad and either the
"+" or "–" pad, depending on the desired offset polarity.
3. Re-enter your "F0" and "F1" values (or ZRO and FRC
commands)—"F1" or FRC being entered with or without
calibration "shunt."
Optional Model 10CJB-2 Bridge Completion Card F
F.5
Cabling & Calibration of a 4077 That Uses an
To Next Page
