• Turn the “HIGH FREQUENCY COMPENSATION” rotary encoder
according to the type of installation and angle set in the line-
array. This rotary encoder affects the medium to high frequency
sections and must be turned to the following position:
STACKED
• 1 - installation in a stacked conguration (for example on
subwoofer through the specially designed DRK-10 y-bar), for an
equalisation with no emphasis over the whole frequency range.
• 2 - installation in a stacked conguration (for example on
subwoofer through the specially designed DRK-10 y-bar), for an
equalisation emphasising high frequencies
FLOWN
• 3 - installation in a own conguration, with the audience
0-20 m away and an angle between each module ranging
between 0° and 4.5°
• 4 - installation in a own conguration, with the audience
0-20 m away and an angle between each module ranging
between 6° and 15°
• 5 - installation in a own conguration, with the audience
21-30 m away and an angle between each module ranging
between 0° and 4.5°
• 6 - installation in a own conguration, with the audience
21-30 m away and an angle between each module ranging
between 6° and 15°
• 7 - installation in a own conguration, with the audience
over 31 m away and an angle between each module
ranging between 0° and 4.5°
• 8 - installation in a own conguration, with the audience
over 31m away and an angle between each module
ranging between 6° and 15°
