47
DVA K5 Code 420120232 REV.1.1
English
PROCESSOR
Internal controller: DSP 25/56 bit/48 kHz
Advanced functions: FIR lters
Limiter: Peak, ermal
INPUTS AND OUTPUTS
Power supply inputs and links: PowerCON In/Link
Audio input: 1x XLR IN, balanced
USB: 1x USB MINI, type B
Audio output: 1x XLR link OUT, balanced
POWER SUPPLY SPECIFICATIONS
Absorption at 1/8 of full power in
audio average use conditions (*):
0,72 A / 76 W (220-240V~) - 1,22 A / 70 W (100-120V~)
Absorption at 1/3 of full power in
audio maximum use conditions (**):
1,25 A / 140 W (220-240V~) - 2,12 A / 144 W (100-120V~)
Nominal full power absorption (***):
2 A (220-240V~) - 4 A (100-120V~)
Draw with speaker turned on without
signal (idle): :
19 W
Inrush current:
18.3 A
Total current and power allowed in
daisy-chain conguration (***):
14 A / 3200 W max (220-240V~) - 11 A / 1200 W max (100-120V~)
USER INTERFACE
Controls: Sensitivity control, 2 8-position rotaries
Led Limiter, Signal, Mute/prot, Ready
* INSTALLER NOTES: The values refer to 1/8 of full power, in average operating conditions (music program with infrequent or no clipping). It
is recommended to consider them the minimum sizing values for any type of conguration.
** INSTALLER NOTES: The values refer to 1/3 of full power, in heavy operating conditions (music program with frequent clipping or activation
of the limiter). We recommend sizing according to these values in case of professional installations and tours.
*** Values obtained using a continuous sinusoidal signal
