dB Technologies K5 - TECHNICAL SPECIFICATIONS DVA K5; General; Acoustic Data; Amplifier

46
DVA K5 Code 420120232 REV.1.1
English
Type: Digipro® G3
Amplication class: D class
Amplication power (Peak) 1000 W
Amplication power(RMS): 500 W
Power supply: SMPS with PSU Auto-range
Power supply connector: (PowerCON In/Link)
Cooling technique: Convection
Controls:
Sensitivity control, 2 rotary encoders with 8 positions
(Coupling, Compensation)
Frequency response [± 3 dB]: 70 - 19000 Hz
Max SPL: 129 dB
HF: 2x 1” (Voice coil:1.4”)
Type HF: Ceramic
MF: 1x 6.5” (Voice coil: 2”)
LF: 1x 8” (Voice coil: 2.5”)
Type MF- LF: Neodymium
Crossover frequency: 340 Hz (Low/Mid), 1800 Hz (Mid/High)
Directivity (HxV): 100°x15° (single module)
Type: 3-way active line-array module
GENERAL
6. TECHNICAL SPECIFICATIONS DVA K5
ACOUSTIC DATA
AMPLIFIER
