Analog Inputs:
Number of Inputs: (6 Total) (2) Switchable line or mic inputs (4) RCA Source
Connectors: Euroblock(Line and Mic) RCA (Source)
Type: Electronically balanced/RF filtered
Impedance: > 50kΩ Balanced, >75kΩ Unbalanced
Max input line level: +20dBu Mic/Line, +12dBu RCA
CMRR: > 40dB, typically >55db @ 1kHz
Mic Pre gain: 30 to 60dB
Mic EIN: < 118dB, 22Hz-22kHz, 150Ω
Mic Phantom Power: 15V
Analog Outputs:
Number of Outputs: (4)
Connectors: Euroblock
Type: Electronically balanced, RF filtered
Impedance: 120 Ω balanced, 60Ω unbalanced
Max Output Level: +20dBu
A/D Performance:
Type: dbx Type IV™ conversion system
Dynamic Range line: >113 dB A-weighted, >110 dB unweighted
Type IV dynamic range: >119 dB, A-weighted, 22kHz BW
>117 dB, unweighted, 22kHz BW
Sample Rate: 48kHz
D/A Performance:
Dynamic Range: 112 dB A-weighted, 109dB unweighted
System Performance:
Dynamic Range: >109 dB A-weighted, >106dB unweighted,
THD+N: 0.003% typical at +4dBu, 1kHz, 0dB gain
Frequency Response: 20Hz – 20kHz, +/- 0.5dB
Interchannel Crosstalk: >80dB typical
Crosstalk input to output: >80dB
Propagation Delay 0.6 msec
Operating voltage: 100 VAC, 50/60Hz, 120 VAC, 60Hz, 230VAC 50/60Hz
Power Requirements: 29 Watts
Physical:
Weight: 6.8 lbs.(3.1 kg) Shipping weight 8.8 lbs. (4.0 kg)
Dimensions: 1.75” H x 5.75” D x 19” W
A.2 - Specifications
Appendix
ZonePro
™
ZonePro™ User Manual
45
