ZonePro™ User Manual
50
Appendix
ZonePro
™
Diagram A Diagram B
Diagram C
Cable Specification: Cat 5 Cable - 4-Twisted Pairs of 24 AWG wire
RJ-45
(8-Position)
RJ-45
(8-Position)
White/Orange
Orange
White/Green
White/Blue
Green
Blue
White/Brown
Brown
-VREF
-Zone 1
-Zone 2
-Zone 4
-Zone 3
-Zone 5
-Zone 6
-GND
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
