Power requirements
Units may be set for 100, 115/120, 200, 215/220 or 230/240V (+/-10%),
50/60Hz AC operation.
Typical power
consumption
Maximum power
consumption
Purcell &
Verona
16W 20W
Delius 21W 25W
Elgar Plus 34W 40W
Verdi &
La Scala
25W 50W
Table 7 – Power consumption for consumer products
Size and Weight
Length Depth Height Weight
Purcell &
Verona
461mm
(18.15”)
413mm
(16.18”)
69mm
(2.70”)
8.5kg
(18.7lbs)
Delius
461mm
(18.15”)
413mm
(16.18”)*
69mm
(2.70”)
8.8kg
(19.4lbs)
Elgar Plus
461mm
(18.15”)
406mm
(16.0”)
75mm
(2.94”)
12.0kg
(26.4lbs)
Verdi &
La Scala
461mm
(18.15”)
415mm
(16.34”)**
137mm
(5.39”)
17kg
(37.4lbs)
Table 8 – Size and weight for consumer products
• *Delius only: the control knob protrudes out of the front by 20mm (0.79”).
• **Verdi & La Scala only: the control knob protrudes out of the front by 13mm
(0.51”).
• Allow extra depth for cable connectors.
Operating Conditions
• Ambient temperature range: 0°C (32°F) to 50°C (122°F), non-condensing.
• Do not install the unit near heat sources such as radiators, air ducts, power
amplifiers or direct strong sunlight.
• If in doubt, the easy test is - Elgar Plus is happy to work anywhere a human
is.
