dCS Elgar Plus User Manual Manual for Software Issue 4.3x
dCS Ltd August 2005
Manual filename: Elgar Manual v4.4x.doc Page 50 email: more@dcsltd.co.uk
English version web-site: www.dcsltd.co.uk
dCS IR Remote Control Codes
This section gives details of the Remote Control codes generated by dCS IR
Remote Control units, for use with programmable remote controls. All dCS
Remote Control units use the RC5 system and a carrier frequency of 37.9kHz.
For more information on the use of dCS Remote Control units, please refer to
the manual for that unit.
IMPORTANT! Please note that dCS cannot accept responsibility for any difficulties
experienced with other manufacturer’s remote control units.
Upsampler
For Purcell, the category code is 29 (decimal).
These Upsampler codes are in use on the Elgar Plus / Delius Remote v2.0 and
Transport Remote v2.0.
Button Code
Decimal
Hexadecimal
Purcell
RC button
1 01 RCA1 / RCA2
3 03 AES1 / AES2
6 06 BNC
7 07 Display
12 0C Standby
14 0E Filter
16 10 (up)
17 11 (down)
26 1A Function
27 1B Input
32 20 32kS/s out
33 21 44.1kS/s out
34 22 48kS/s out
35 23 88.2kS/s out
36 24 96kS/s out
37 25 176.4kS/s out
38 26 192kS/s out
39 27 DSD/1394 out
41 29 Standby ON
42 2A Standby OFF
43 2B Power OFF
44 2C Filter 1
45 2D Filter 2
46 2E Filter 3
47 2F Filter 4
