Parts List Oven Door
13
ITEM DESCRIPTION 127/227 PART NO. 130/230 PART NO.
1 DOOR SEAL 96068 96166
2 INNER DOOR GLASS 14193-01 14192-02
3 DOOR SEAL CHANNEL 96073
4 DOOR LINER W/ASSEMBLY 96118-PC 96213-PC
5 HINGE TOP BRACKET 96001
6 DOOR INSULATION COVER 96070 96192
7 GLASS SPACER 96071 96193
8 INNER DOOR GLASS 14193-01 14193-02
9 GLASS COVER TOP & BOTTOM 96066 96189
10 GLASS COVER SIDE 96067
11 DOOR HEAT SHIELD 96137 96195
12 OUTSIDE DOOR GLASS (BLACK) 14194-01 14194-03
* OUTSIDE DOOR GLASS (WHITE) 14194-02 14194-04
13 HANDLE STIFFENER 96012
14 DOORSKIN S/STEEL NO LOGO 96113-01 96212-01
* DOORSKIN S/STEEL WITH LOGO 96113-02 96212-02
* DOORSKIN BLACK NO LOGO 96113-08-PA 96212-08-PA
* DOORSKIN BLACK WITH LOGO 96113-07-PA 96212-07-PA
* DOORSKIN BLUE NO LOGO 96113-10-PA 96212-10-PA
* DOORSKIN BLUE WITH LOGO 96113-09-PA 96212-09-PA
* DOORSKIN GREEN NO LOGO 96113-12-PA 96212-12-PA
* DOORSKIN GREEN WITH LOGO 96113-11-PA 96212-11-PA
* DOORSKIN PLATINUM NO LOGO 96113-14-PA 96212-14-PA
* DOORSKIN PLATINUM WITH LOGO 96113-13-PA 96212-13-PA
* DOORSKIN WHITE NO LOGO 96113-06-PA 96212-06-PA
* DOORSKIN WHITE WITH LOGO 96113-05-PA 96212-05-PA
15 HANDLE SPACER 12167
16 DOOR HANDLE 12122 12239
* DOOR HANDLE PLATED BRASS 12122-05-PL-B
17 LOGO 17255-01
18 LOGO CLIPS 15073
19 HINGE 150034-1
20 HINGE BOTTOM PLATE 96021
* PLATE SCREWS (4) 15001-22
21 END CAP SS PRO-STYLE 18164-PL 18164-PL
22 DOOR HANDLE SS PRO-STYLE 96139-07 96139-32
23 HANDLE STIFFENER 96102 96102
24 DOOR SKIN S/S NO LOGO 96159-01
* DOOR HANDLE PRO STYLE BRASS 90187-11-PL-B 90187-13-PL-B
* ITEMS NOT SHOWN
