DCS WO-227SS - Latch Removal; Upper and Lower Latch Assembly

39
Latch Removal
UPPER AND LOWER
STEP 1
Remove oven door. With a phillips screwdriver remove the five (5) screws securing the latch cover
bottom and top (figs.21 & 22).
STEP 2
Latch assembly can now be pulled forward to access the rear of latch assembly (fig.23).
NOTE: It is always wise to transfer wires while the original latch is still in place. This
ensures the correct wires are connected to the correct terminals.
FIG.23
FIG.21
FIG.22
