DCS WO-227SS - Specifications

Specifications / D imensions
7
Bottom Trim screws
25-1/2"
23-7/8"
54-3/16 "
54-15/16 "
29-7/8"
Interior Dimension = 16"H x 25"W x 18-5/8"D
Rack Dimension = 24-3/8"W x 15"D
Front
Side
WO-230 30” Double Wall Oven
Conduit
box centered
2" below bottom
of oven
2x4's or
similar
runners
or solid
structure
support
30"
2x4's or
similar supports
Floor
(Suggested
distance from
floor 6" min.)
min.
WALL OVEN
Cut Out Dimensions
WALL OVEN
Cabinet Dimensions
54-3/8 "
28-1/2 "
