Parts List Upper Oven
19
ITEM DESCRIPTION 127/227 PART NO. 130/230 PART NO.
1 OUTER AIR JACKET TOP 96008 96170
2AIR DUCT 96049 96181
3LATCH COVER TOP 96132 96188
4CATALYST DUCT W/ASSEMBLY 96114
5 BLOWER MOTOR 16258
6 BLOWER THERMOSTAT 16255
7 BLOWER MOTOR BRACKET 96134
8CATALYST DUCT BRACKET 96133
9LATCH RETAINER 96083
10 DOOR LATCH 16247
11 LATCH MOUNT 96082
12 LATCH COVER BOTTOM 96064
13 UPPER AIR JACKET 96062 96186
14A OUTSIDE AIR JACKET R/H 96076-01
14B OUTSIDE AIR JACKET L/H 96076-02
15 SIDE TRIM W/ASSEMBLY L/H 96112-02 96112-04-PA
15A SIDE TRIM W/ASSEMBLY R/H 96112-01 96112-03-PA
16A INSIDE AIR JACKET R/H 96075-01
16B INSIDE AIR JACKET L/H 96075-02
17 HINGE POCKET 96025
18 BROIL TERMINAL BOX 96063
19 LOWER AIR JACKET 96043 96178
20 LOWER INTAKE DUCT BOTTOM UPPER OVEN 96080-01 96196-01
21 DRIP BRACKET 96053 96183
22 MIDDLE FRONT AIR DAM 96042 96218
23 MIDDLE PANEL W/ASSEMBLY 96129-01 96176-01
24 B/ MOTOR AIR CHAMBER (UPPER OVEN ONLY) 96081
25 REAR AIR JACKET 96040 96177
26 CONVECTION TOP INS. RETAINER 96013
27 BOTTOM CONVECTION INS. RETAINER 96048
28 CONVECTION CHANNEL 96052
29 BLOWER MOTOR REAR AIR GUARD 96059
30 CONVECTION DUCT 96084
31 BACK COVER 96072 96194
32 CONTROL BOX BOTTOM L/H 96029-02
33 CONTROL BOX BOTTOM R/H 96029-01
34 HINGE COVER 96032
35 CATALYST DUCT SCOOP 96041
36 DOOR LIGHT SWITCH 16173
37 HI-TEMP CUTOUT 13043-01
38 HI-TEMP BRACKET 96033
39 HINGE RECEPTACLE 15136
* ITEMS NOT SHOWN
