5. Place the drip tray.
6. Place the jug stand on the guides (2) and slide it in the
direction of the arrow.
NOTE
Make sure that the ledges on the back of the jug stand
(3) fit inside the notches in the door (1).
7. Push the jug stand down to secure it properly to the door and
the support guides (2).
8. Depending on the model: place the metal inlay grid.
57
Virtu CEC Medium Cabinet 70/90 CoEx® brewer User Manual 5DUCEK20M EN V2.1
