DSE Model 8620 AMF Controller Operators Manual
89
7.3 WARNINGS
Warnings are non-critical alarm conditions and do not affect the operation of the generator system,
they serve to draw the operators attention to an undesirable condition.
Example
Alarm 1/1
Charge Failure
Warning
In the event of an alarm the LCD will jump to the alarms page, and scroll through all active warnings
and shutdowns.
By default, warning alarms are self-resetting when the fault condition is removed. However enabling ‘all
warnings are latched’ will cause warning alarms to latch until reset manually. This is enabled using the
8600 series configuration suite in conjunction with a compatible PC.
Display Reason
AUXILIARY INPUTS If an auxiliary input has been configured as a warning the appropriate LCD
message will be displayed and the COMMON ALARM LED will illuminate.
CHARGE FAILURE The auxiliary charge alternator voltage is low as measured from the W/L terminal.
BATTERY UNDER
VOLTAGE
The DC supply has fallen below the low volts setting level for the duration of the low
battery volts timer
BATTERY OVER VOLTAGE The DC supply has risen above the high volts setting level for the duration of the
high battery volts timer
FAIL TO STOP The module has detected a condition that indicates that the engine is running when
it has been instructed to stop.
NOTE:- ‘Fail to Stop’ could indicate a faulty oil pressure sensor or switch - If the
engine is at rest check oil sensor wiring and configuration.
FUEL USAGE Indicates the amount of fuel measured by the fuel level sensor is in excess of the
Fuel Usage alarm settings. This often indicates a fuel leak or potential fuel theft.
FAILED TO SYNCHRONISE, if the module cannot synchronise within the time allowed by the Synchronising timer
a warning is initiated. The LCD will indicate ‘FAILED TO SYNC’ and the COMMON
ALARM LED will illuminate
AUXILIARY INPUTS Auxiliary inputs can be user configured and will display the message as written by
the user.
LOW FUEL LEVEL The level detected by the fuel level sensor is below the low fuel level setting.
CAN ECU ERROR The engine ECU has detected a warning alarm and has informed the DSE module
of this situation. The exact error is also indicated on the module’s display.
kW OVERLOAD The measured Total kW is above the setting of the kW overload warning alarm
EARTH FAULT The measured Earth Fault Current has been in excess of the earth fault trip and has
surpassed the IDMT curve of the Earth Fault alarm.
NEGATIVE PHASE
SEQUENCE
Indicates ‘out of balance’ current loading of the generator.
Sometimes also called Negative Sequence Current or Symmetry Fault
MAINTENANCE DUE Indicates that the maintenance alarm has triggered. A visit is required by the
Generator service company.
MAINS REVERSE POWER if the 8620 detects that the generator is exporting more than the configured limit,
the LCD will indicate ‘MAINS REVERSE POWER’ and the COMMON ALARM LED
will flash
LOADING VOLTAGE NOT
REACHED
Indicates that the generator voltage is not above the configured loading voltage.
The generator will not take load when the alarm is present after the safety timer.
LOADING FREQUENCY Indicates that the generator frequency is not above the configured loading
