Deger D25H - Abridged Assembly Instructions for the Degertracker

01.01.2022 ASSEMBLY AND OPERATING MANUAL DEGER D25H, D60H, D80 and D100 Page 15
4 Abridged assembly instructions for the DEGER
systems
 Read the complete assembly instructions before starting assembly work
 Pay attention to all safety notes in the assembly instructions
1.
Erect the mast, install the supply lines
______________________________________________________________________________________
2.
Assemble the base frame
______________________________________________________________________________________
3.
Assemble the aluminium profiles to the base frame
______________________________________________________________________________________
4.
Mount the rotating head to the mast
______________________________________________________________________________________
5.
Assemble the elevation drive (EMO)
______________________________________________________________________________________
6.
Mount the solar modules on the aluminium profiles
______________________________________________________________________________________
7.
Assemble the MLD-control
Exemplary picture
DEGER systems D100
Exemplary picture
DEGER systems D100
Exemplary picture
DEGER systems D100
Exemplary picture
DEGER systems D100
