Deger D25H - Install MLD Control System; Connection Diagram

01.01.2022 ASSEMBLY AND OPERATING MANUAL DEGER D25H, D60H, D80 and D100 Page 31
7 Install MLD control system
7.1 Connection diagram
ATTENTION!
Connection plans, as well as further details on the control including all individual components can
be found in the assembly manual “MLD Control EC-6 with CCB”.
Optional:
sunlight sensor
EC-6 with MLD sensors
CCB with joystick
Standard Wind monitor
Optional: Snow Sensor
Pin 1, 2, 3, 4
Pin 16, 17, 18, 19
Cable: br, bl, bk
Pin + - 20
