Dehler 34 - Page 10

D E H L E R 3 4

A = maximum length
(bow sprit)
: 11.00 m
A = maximum length: 10.70 m
B = hull length: 10.30 m
C = height hull – instrument console: 2.40 m
D = height hull – pulpit: 2.45 m
E = beam of hull: 3.60 m
keel dimension:
shallow keel standard L-keel deep keel
F 1.53 m 1.62 m 1.58 m
G 1.94 m 1.70 m
H 2.11 m 2.18 m 2.22 m
I 1.04 m 1.48 m 1.65 m
J 0.42 m 0.38 m 0.41 m
shallow keel
deep keel
standard L
-
keel
