1.5.1. Direct current system
The direct current system is in charge of starting the engine and supplying power to the
navigation instruments, the lighting and part of the electrical equipment on board.
Use the 220 Volt system when connected to shore power.
The power is distributed via the switchboard in the saloon. The circuits have switches so that the
consumers can be switched on and off centrally. All power circuits within the system must be
protected against overload by fuses. The fuses indicate whether there is a failure in the system.
The circuit diagram can be made available by your dealer if required.
Interior lights Tricolor
Navigation lights Deck wash pump
Anchor light Bilge pump with hose
Steaming lights Stern door control
Refrigerator / freezer Main furler system
Freshwater pump Dinghywinsch
Bilge pump – manual override Reserve
Navigation electronics Black water pump
Anchor winch
Winch control
Bild 10 DC-Panell
