1.3.5. General arrangement
C1 B1 A1
C1 B1 A2
1.4. Propulsion system
1.4.1. Engine, Engine room, reduction gear
The engine room is located underneath the companionway from the deck to the saloon. The
complete propulsion system and all auxiliary equipment, necessary for the operation of the yacht,
are located here.
The engine room is separated from living compartments and is ventilated electrical. The engine
room is provided with a flame-resistant insulation. The engine room can be accessed either by
lifting up the companionway stairs or through a side doors.
Never remove the protections from rotating parts whilst the engine
is running. Never touch the rotating parts. Only step on the areas
provided for. 
The engine room is not stowage space. Do not leave loose objects
lying around. Store inflammable liquids in appropriate vessels in
boxes or locker seats in the outside area!

Fig.
2
General
arrangement
