D E H L E R 3 4
Chapter 2 – Further Technical Details
1. Installations and Systems
1.1. Tank capacities
1 Fuel tank approx. 156 l The tank is located underneath the bed in the
starboard aft cabin. He is equipped with an
electrical transmitting device, a manhole and
connecting conduits with valves, as well as
ventilation.
1 Fresh water tank approx. 210 l The fresh water tank is equipped with an
inspection lid, valves and ventilation. The tank is
located under the bed in the bow.
1 Black water tank approx. 35 l The tank is located in the immediate vicinity of the
toilet.
The tank is permanently installed. The system
includes appropriate valves and deck openings to
pump-out the content on shore and a seacock for
direct discharge into the sea.
In the fixed fuel and water tanks, it is possible that all the capacity
may not be usable according trim and loading.
In the fuel tank, a reserve of 20% should be kept.
