Statistics data
Press the H and E keys simultaneously to go from the regular display mode to
the statistic mode.
Max./min. values can be reset in system mode.
Screen no. 1
Max. value of phase-neutral voltage U1_max
Max. value of phase-neutral voltage U2_max
Max. value of phase-neutral voltage U3_max
►V/A
Screen no. 2
Min. value of phase-neutral voltage U1_min
Min. value of phase-neutral voltage U2_min
Min. value of phase-neutral voltage U3_min
►V/A
Screen no. 3
Max. value of phase-phase voltage U12_max
Max. value of phase-phase voltage U23_max
Max. value of phase-phase voltage U31_max
►V/A
Screen no. 4 changes from max. to min.
►V/A
Screen no. 5
Max. value of the current I1_max
Max. value of the current I2_max
Max. value of the current I3_max
►V/A
Screen no. 6 changes from max. to min.
►V/A
