PPM Installation Instructions
DEIF A/S Page 38 of 69
Slot #4, not used
Slot #5, AC measuring
Term. Function Technical data Description
73 I L1 s1 Generator current L1 1/5 A AC input
74 I L1 s2
75 I L2 s1 Generator current L2 1/5 A AC input
76 I L2 s2
77 I L3 s1 Generator current L3 1/5 A AC input
78 I L3 s2
79 U L1 Generator voltage L1 Max. 690V AC phase - phase value
80 Not used
81 U L2 Generator voltage L2 Max. 690V AC phase - phase value
82 Not used
83 U L3 Generator voltage L3 Max. 690V AC phase - phase value
84 U neutral Generator voltage
neutral
For land based applications only
85 U L1 Bus voltage L1 Max. 690V AC phase - phase value
86 Not used
87 U L2 Bus voltage L2 Max. 690V AC phase - phase value
88 U neutral Bus voltage neutral For land based applications only
89 U L3 Bus voltage L3 Max. 690V AC phase - phase value
Current inputs are galvanically separated. Max. 0.3 VA per phase. Voltage
measurements are available (phase to phase) from 100V AC to 690V AC.
