PPM Installation Instructions
DEIF A/S Page 40 of 69
Option M18
4 x relay outputs.
Term. Function Description
90 Relay output 14
250V AC, 8A max.
Configurable
91
92 Relay output 15
250V AC, 8A max.
Configurable
93
94 Relay output 16
250V AC, 8A max.
Configurable
95
96 Relay output 17
250V AC, 8A max.
Configurable
97
Slot #7, engine interface board
Term. Function Technical data Description/preconfiguration
98 Analogue input 1 + +4…20 mA in Heavy consumer 1 variable load/configurable
99 Analogue input 1 - GND
100 Analogue input 2 + +4…20 mA in Heavy consumer 2 variable load/configurable
101 Analogue input 2 - GND
102 Analogue input 3 + +4…20 mA in Configurable. User-programmable
103 Analogue input 3 - GND
104 Binary input With wire break
supervision
Wire break
resistor: 100 
Configurable. User-programmable
This input will need a potential free contact
105 Binary input Configurable. User-programmable
This input will need a potential free contact
106 Binary input Configurable. User-programmable
This input will need a potential free contact
107 Common Common terminals for 104-106
108 Tacho input 0.5…70V AC
10…10.000 Hz
RPM/magnetic pick-up/overspeed
109 Tacho input
110 Binary input Optocoupler Configurable. User-programmable
111 Binary input Optocoupler Configurable. User-programmable
112 Binary input Optocoupler Configurable. User-programmable
113 Binary input Optocoupler Configurable. User-programmable
114 Binary input Optocoupler External emergency stop activated
115 Binary input Optocoupler Ready for operation (ON = ready, OFF = blocked)
116 Binary input Optocoupler Running feedback
117 Binary input Optocoupler Configurable. User-programmable
118 Binary input Optocoupler Configurable. User-programmable
119 Com. Common Common for terminals 114-118
120 NO Relay no. 18
250V AC/8A
Not used
121 Com.
122 NO Relay no. 19
250V AC/8A
Not used
123 Com.
124 NO Relay no. 20
250V AC/8A
Not used
125 Com.
