DeLaval MA200 - Milking Automation Modules Type Plates

Preliminary
941322_VMS Instruction Book 2006.pdf2009-09-07
No. Name Range Default Description/optionsNo. Name Range Default Description/options
0 = no acidic cleaning0 = no acidic cleaning
1 = one alkaline, one acidic cleaning1 = one alkaline, one acidic cleaning
2 = two alkaline, one acidic cleaning2 = two alkaline, one acidic cleaning
3 = etc.3 = etc.
Maintenance an calibration
The following points are important to sustain
correct dosing of etergents. Note that
these two tasks should be performed by an
authorised DeLaval service engineer.
• The tubes in the peristaltic pumps should
be replaced at least two times a year.
• The dosing volume (P6-P8) of the
detergent pumps should be checked
every third month. The dosing capacity
(P32-P34) may need to be adjusted.
Starting cleaning or rinsing
from the touch screen
Note: Any ongoing backflush process must
first be finished before cleaning or rinsing
can be started.
1. Ensure that the milking station is in
manual mode.
2. Remove any cow that might be in the
milking station.
After treatment window
Note: Both gates should be closed to
prevent a cow from entering before the
system cleaning has been started. Closing
and opening gates is done in the Stall
control window.
3. Press the tab After Treatment on the
touch screen to display the After treatment
window.
4. In the After treatment window, press the
Cleaning and Rinsing button. This will open
the Cleaning and rinsing window.
8.2 Type plate on milking automation
modules
The type plates on the modules are located at the
bottom of the module box and on the potting
compund covering the PCB on the inside of the
module, see . The type plates contains the infor-
mation shown in and a field description is given
in the table below.
DeLaval International AB
P.O. Box 39
SE-147 21 Tumba, Sweden
Made in Sweden
Type: Input/Output Module
Model: IOM 200
Art No: 2150003488
Serial no : HB00005
ID: A48E0A800057
Supply voltage: 24VDC, 5W,
output load excluded
DeLaval International AB
P.O. Box 39
SE-147 21 Tumba, Sweden
Made in Sweden
Type: Control and
communication Module
Model: CCM 215
Art No: 2150005045
Serial no : HB00005
ID: A48E0A800057
Supply voltage: 24VDC, 5W,
output load excluded
11
14
15
18
19
22
23
7
6
3
2
5
4
1
8
9
10
13
16
17
20
21
24
12
11
18
19
22
23
7
6
3
2
5
4
1
8
9
10
17
20
21
24
12
ETH
A B
Model:
Art No:
ID:
www.delaval.com
Serial No:
275618
Fig. 2: Type plate locations on the modules. The
Button Module is used as an example.
A: Type plate layout for Button module and Input/
output module
B: Type plate layout for Communication and control
module
C: Small type plate layout for all modules
DeLaval milking automation MA200 (Test installation)
Safety precautions
© DeLaval 2019.
2019-05-31, Version 1 10 (62)
