1
Your computer configuration determines which COM port is used for the Disk Array USB Port.
2
Verify the appropriate COM port for use with the CLI.
4. If necessary, press Enter to display login prompt.
a) Type the user name of a user with the manage role at the login prompt and press Enter.
b) Type the password for the user at the Password prompt and press Enter.
Topics:
• Mini-USB Device Connection
Mini-USB Device Connection
The following sections describe the connection to the mini-USB port:
Emulated serial port
When a computer is connected to a controller module using a mini-USB serial cable, the controller presents an emulated serial port to the
computer. The name of the emulated serial port is displayed using a customer vendor ID and product ID. Serial port configuration is
unnecessary.
NOTE: Certain operating systems require a device driver or special mode of operation to enable proper functioning of
the USB CLI port. See also Device driver/special operation mode.
Supported host applications
The following terminal emulator applications can be used to communicate with an ME4 Series controller module:
Table 29.
Supported terminal emulator applications
Application Operating system
PuTTY Microsoft Windows (all versions)
Minicom Linux (all versions)
Command-line interface
When the computer detects a connection to the emulated serial port, the controller awaits input of characters from the computer using
the command-line interface. To see the CLI prompt, you must press Enter.
NOTE:
Directly cabling to the mini-USB port is considered an out-of-band connection. The connection to the mini-USB
port is outside of the normal data paths to the controller enclosure.
Device driver/special operation mode
Certain operating systems require a device driver or special mode of operation. The following table displays the product and vendor
identification information that is required for certain operating systems:
USB identification code type
Code
USB Vendor ID 0x210c
USB Product ID 0xa4a7
136 Connecting to the CLI port using a serial cable
