Dell EMC Unity Series Installation Guide

Unpack the disk processor enclosure
The disk processor enclosure (DPE) is a 2U component with either 12 3.5" drive slots
or 25 2.5" drive slots. Verify that you have received all of the DPE components,
including cables, bezel, rail kit, and mounting screws.
Verifying shipping package contents
Confirm that you received all necessary equipment needed to install the new 2U DPE.
Verify that you received the following:
Component
Disk processor enclosure (DPE)
- 2U component with either:
25 2.5" drive slots
or
12 3.5" drive slots
Front view 25 2.5" drive slots
240
Will Make the Array Unusable
Caution: Array Software on drives 0-3. Removing or relocating them
or
Front view 12 3.5" drive slots
0
SAS12Gb
SAS12Gb
SAS12Gb
SAS12Gb
SAS12Gb
SAS12Gb
SAS12Gb
SAS12Gb
SAS12Gb
SAS12Gb
SAS12Gb
SAS12Gb
3
Removing these drives will
make the array unusable
SPD
Removing these drives will
make the array unusable
SPD
Removing these drives will
make the array unusable
SPD
Removing these drives will
make the array unusable
SPD
Rail kit (1, includes 2 rails and 6
screws)
CL5583
Power cords
Unpack your system
14 Unity 300/300F, Unity 350F, Unity 380/380F, Unity 400/400F, Unity 450F, Unity 500/500F, Unity 600/600F
and Unity 650F Installation Guide

Dell EMC Unity Series Specifications

General

Snapshot Support	Yes
Storage Type	Hybrid Flash, All-Flash
Drive Support	SAS, SSD
Protocols	iSCSI, NFS, SMB
Data Services	Snapshots, Replication, Thin Provisioning, Deduplication, Compression
Management	Unisphere, REST API, CLI
Data Reduction Features	Deduplication, Compression
High Availability	Redundant components
Redundancy	power supplies, fans
RAID Levels Supported	RAID 5, RAID 6, RAID 10
Replication Support	Yes
Cloud Tiering	Yes
Security Features	Encryption at rest, secure erase, role-based access control
Model	Dell EMC Unity Series
