Dell EMC Unity Series Installation Guide

Figure 28 Bus 2, Bus 3 , Bus 4, and Bus 5 enclosure 0 SAS cabling
AC
DC
1 GbE
AC
DC
x4
1 GbE
4
5
1
1
4
5
4
5
4
5
0 1 2 3
0 1 2 3
SP A A0 PORT 0
SP A A0 PORT 1
SP A A0 PORT 2
SP A A0 PORT 3
0
1
x4
0
1
x4
LCC A Port A
LCC A Port A
LCC A Port A
LCC A Port A
SP B B0 PORT 0
SP B B0 PORT 1
SP B B0 PORT 2
SP B B0 PORT 3
LCC B Port A
LCC B Port A
LCC B Port A
LCC B Port A
2_0
3_0
4_0
5_0
2_0
3_0
4_0
5_0
l
2_0 side A, black, SP A B0 port 0 to DAE <
w > LCC A port A
l
2_0 side B, black, SP B B0 port 0 to DAE <
w > LCC B port A
l
3_0 side A, green, SP A B0 port 1 to DAE < x > LCC A port A
l
3_0 side B, green, SP B B0 port 1 to DAE <
x > LCC B port A
l
4_0 side A, brown, SP A B0 port 2 to DAE < y > LCC A port A
l
4_0 side B, brown, SP B B0 port 2 to DAE < y > LCC B port A
l
5_0 side A, cyan, SP A B0 port 3 to DAE < z > LCC A port A
l
5_0 side B, cyan, SP B B0 port 3 to DAE < z > LCC B port A
For each new BE2-BE5:
Procedure
1. Label a pair of mini-SAS HD cables using the appropriate labels (black, green,
brown, or cyan) shown here.
Cable and power up your DAE components
Cabling the DPE SAS module ports to create back-end buses 2 through 5 59

Dell EMC Unity Series Specifications

General

Snapshot Support	Yes
Storage Type	Hybrid Flash, All-Flash
Drive Support	SAS, SSD
Protocols	iSCSI, NFS, SMB
Data Services	Snapshots, Replication, Thin Provisioning, Deduplication, Compression
Management	Unisphere, REST API, CLI
Data Reduction Features	Deduplication, Compression
High Availability	Redundant components
Redundancy	power supplies, fans
RAID Levels Supported	RAID 5, RAID 6, RAID 10
Replication Support	Yes
Cloud Tiering	Yes
Security Features	Encryption at rest, secure erase, role-based access control
Model	Dell EMC Unity Series
