Dell EMC Unity Series Installation Guide

Expansion port cable labeling details Primary port cable labeling details
Label part
number
Label Port Label part
number
Label Port
046-004-456
A BE1
046-004-456_xx
A BE1
A BE1
A BE1
LCC A Port B 046-004-456
A BE1
046-004-456_xx
A BE1
A BE1
A BE1
LCC A Port A
046-004-464
B BE1
046-004-464_xx
B BE1
B BE1
B BE1
LCC B Port B 046-004-464
B BE1
046-004-464_xx
B BE1
B BE1
B BE1
LCC B Port A
046-004-457
A BE2
046-004-457_xx
A BE2
A BE2
A BE2
LCC A Port B 046-004-457
A BE2
046-004-457_xx
A BE2
A BE2
A BE2
LCC A Port A
046-004-465
B BE2
046-004-465_xx
B BE2
B BE2
B BE2
LCC B Port B 046-004-465
B BE2
046-004-465_xx
B BE2
B BE2
B BE2
LCC B Port A
046-004-458
A BE3
046-004-458_xx
A BE3
A BE3
A BE3
LCC A Port B 046-004-458
A BE3
046-004-458_xx
A BE3
A BE3
A BE3
LCC A Port A
046-004-466
B BE3
046-004-466_xx
B BE3
B BE3
B BE3
LCC B Port B 046-004-466
B BE3
046-004-466_xx
B BE3
B BE3
B BE3
LCC B Port A
046-004-459
A BE4
046-004-459_xx
A BE4
A BE4
A BE4
LCC A Port B 046-004-459
A BE4
046-004-459_xx
A BE4
A BE4
A BE4
LCC A Port A
Cable and power up your DAE components
64 Unity 300/300F, Unity 350F, Unity 380/380F, Unity 400/400F, Unity 450F, Unity 500/500F, Unity 600/600F
and Unity 650F Installation Guide
