Removing and installing Field Replaceable
Units (FRUs)
The replaceable components in this chapter are Field Replaceable Units (FRUs).
CAUTION: The information in this section is intended for authorized service technicians only.
CAUTION: To avoid any potential damage to the component or loss of data, ensure that an authorized service
technician replaces the Field Replaceable Units (FRUs).
CAUTION: Dell Technologies recommends that this set of repairs, if needed, to be conducted by trained
technical repair specialists.
CAUTION: As a reminder, your warranty does not cover damages that may occur during FRU repairs that are not
authorized by Dell Technologies.
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
Display assembly
Removing the display assembly
Prerequisites
1. Follow the procedure in Before working inside your computer.
NOTE:
Ensure that your computer is in Service Mode. For more information, see step 7 in Before working inside your
computer.
2. Remove the base cover.
About this task
The following images indicate the location of the display assembly and provide a visual representation of the removal procedure.
