Figure 54. Palm-rest and keyboard assembly
Steps
After performing the steps in Prerequisites, you are left with the palm-rest and keyboard assembly.
NOTE:
The palm-rest and keyboard assembly consists of the following:
● Palm rest
● Keyboard
Installing the palm-rest and keyboard assembly
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation process.
About this task
NOTE:
If either the system board or the heat sink is replaced, use the thermal grease that is provided in the kit to ensure
that thermal conductivity is achieved.
The following image shows the palm-rest and keyboard assembly.
Removing and installing Field Replaceable Units (FRUs)
79
