2. Install the base cover.
3. Follow the procedure in After working inside your computer.
Palm-rest and keyboard assembly
Removing the palm-rest and keyboard assembly
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
NOTE: Ensure that your computer is in Service Mode. For more information, see step 7 in Before working inside your
computer.
2. Remove the base cover.
3. Remove the battery.
4. Remove the battery cable.
5. Remove the M.2 2230 solid state drive.
6. Remove the display assembly.
7. Remove the fan.
8. Remove the heat sink.
9. Remove the wireless card.
10. Remove the speaker assembly.
11. Remove the system board.
NOTE: The system board can be removed with the heat sink attached.
12. Remove the I/O board.
13. Remove the power button or the power button with optional fingerprint reader, whichever is applicable.
14. Remove the touchpad.
About this task
The following image shows the palm-rest and keyboard assembly after all other components have been removed.
78
Removing and installing Field Replaceable Units (FRUs)
