2. Align and place the palm-rest and keyboard assembly under the display hinges.
3. Close the left-display hinge and align the screw holes on the left-display hinge with the screw holes on the palm-rest and
keyboard assembly.
4. Replace the two screws (M2.5x5) that secure the left display-assembly hinge to the palm-rest and keyboard assembly.
5. Close the right-display hinge and align the screw holes on the right-display hinge with the screw holes on the palm-rest and
keyboard assembly.
6. Replace the three screws (M2.5x5) that secure the right display-assembly hinge to the palm-rest and keyboard assembly.
7. Connect the infrared camera cable to the connector (CIR) on the system board and close the latch.
8. Connect the display-assembly cable to the connector (LCD) on the system board and close the latch.
9. Adhere the tape that secures the display-assembly cable to the latch on the system board.
Next steps
1. Install the base cover.
2. Follow the procedure in After working inside your computer.
I/O-board cable
Removing the I/O-board cable
CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
1. Follow the procedure in Before working inside your computer.
NOTE:
Ensure that your computer is in Service Mode. For more information, see step 7 in Before working inside your
computer.
2. Remove the base cover.
About this task
The following image indicates the location of the I/O-board cable and provides a visual representation of the removal procedure.
Removing and installing Field Replaceable Units (FRUs)
53
