Procedures:
i. Click the first column of the Access List row 1.
ii. Enter "192.168.200.10" in the Address field and "255.255.255.255" in the Address Mask field.
iii. Select Permit.
iv. Click the first column of the Access List row 2.
v. Enter "192.168.200.0" in the Address field and "255.255.255.0" in the Address Mask field.
vi. Select Reject.
vii. Click the first column of the Access List row 3.
viii. Enter "192.168.0.0" in the Address field and "255.255.0.0" in the Address Mask field.
ix. Select Permit.
x. Click Apply New Settings.

E-Mail Alert
Purpose:
To configure detailed settings for the E-Mail Alert. This page can also be displayed by clicking E-Mail Alert in the left frame.
Values:

SNMP
Purpose:
To configure the detailed settings of SNMP.
Values:
E-Mail Server
Settings
Primary SMTP
Gateway
Sets the primary SMTP gateway.
SMTP Port Number
Specifies the SMTP port number. This must be 25, 587 or between 5000 and 65535.
E-Mail Send
Authentication
Specifies the authentication method for outgoing e-mail.
SMTP Login User
Specifies the SMTP login user. Up to 63 alphanumeric characters, periods, hyphens, under bars, and at symbols
(@) can be used. If specifying more than one address, separate them using commas.
SMTP Login Password
Specifies the SMTP account password using up to 31 alphanumeric characters.
Re-enter SMTP Login
Password
Enter the SMTP account password again to confirm.
POP3 Server
Address*1
Specifies the POP3 server address in IP address format of "aaa.bbb.ccc.ddd" or as a DNS host name using up to
63 characters.
POP3 Port Number*1
Specifies the POP3 server port number. This must be 110 or between 5000 and 65535.
POP User Name*1
Specifies the POP3 account user name. Up to 63 alphanumeric characters, periods, hyphens, under bars, and at
symbols (@) can be used. If specifying more than one address, separate them using commas.
POP User Password*1
Specifies the POP3 account password using up to 31 alphanumeric characters.
Re-enter POP User
Password
Enter the password again to confirm.
Reply Address
Designates the reply e-mail address sent with each E-mail Alert.
SMTP Server
Connection
Displays the status of the SMTP server connection.
E-Mail Alert
Settings
E-Mail List 1
Sets acceptable e-mail addresses for the E-Mail Alert feature using up to 255
alphanumeric characters.
Select Alerts for List 1
Supplies Alerts
Select the check box to receive an E-Mail Alert for consumables.
Paper Handling Alerts
Select the check box to receive an E-Mail Alert for paper handling.
Service Call
Select the check box to receive an E-Mail Alert for Service Calls.
E-Mail List 2
Sets acceptable e-mail addresses for the E-Mail Alert feature using up to 255
alphanumeric characters.
Select Alerts for List 2
Supplies Alerts
Select the check box to receive an E-Mail Alert for consumables.
Paper Handling Alerts
Select the check box to receive an E-Mail Alert for paper handling.
Service Call
Select the check box to receive an E-Mail Alert for Service Calls.
*
1
Available when POP before SMTP (Plain) or POP before SMTP (APOP) for E-Mail Send Authentication is selected.
